Specifications
| Model CC: Mechanical Control · CCR: Remote Control | Dimensions (mm) | Fan Diameter (mm) | Power (V) (Hz) | Air Flow (m³/h) | Capacity (W) | Wind Speed (m/s) | Noise dB(A) | G.W. (kg) | N.W. (kg) | Packing Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| FM-CC/CCR09 | 900 × 190 × 215 | 115–120 | 220–240 50/60 | 960–1150 | 180 | 12 / 10 / 8 | 55–57 | 11.50 | 10.00 | 940 × 240 × 275 |
| FM-CC/CCR10 | 1000 × 190 × 215 | 115–120 | 220–240 50/60 | 1000–1280 | 180 | 12 / 10 / 8 | 55–57 | 12.50 | 10.60 | 1040 × 240 × 275 |
| FM-CC/CCR12 | 1200 × 190 × 215 | 115–120 | 220–240 50/60 | 1200–1760 | 200 | 12 / 10 / 8 | 56–58 | 13.50 | 12.50 | 1240 × 240 × 275 |
| FM-CC/CCR15 | 1500 × 190 × 215 | 115–120 | 220–240 50/60 | 1500–2180 | 220 | 12 / 10 / 8 | 57–59 dB | 16.00 | 14.00 | 1540 × 240 × 275 |
