Specifications
| Model | Dimensions (mm) | Voltage (V) | Frequency (Hz) | Input power (V) | PTC power (W) | Air Flow (m³/h) | Wind Speed (m/s) | Noise dB(A) | Packing Size (mm) |
|---|---|---|---|---|---|---|---|---|---|
| FM-CCH09 | 900 × 190 × 215 | 220~240/380 | 50/60 | 180 | 7.4kW | 960–1120 | 7~9 | 45 | 940 × 240 × 275 |
| FM-CCH10 | 1000 × 190 × 215 | 220~240/380 | 50/60 | 200 | 8.2kW | 960-1120 | 7~9 | 45 | 1040 × 240 × 275 |
| FM-CCH12 | 1200 × 190 × 215 | 220~240/380 | 50/60 | 220 | 9.2kW | 1080-1380 | 7~9 | 46 | 1240 × 240 × 275 |
| FM-CCH15 | 1500 × 190 × 215 | 220~240/380 | 50/60 | 230 | 11.4kW | 1280-1580 | 7~9 | 48 | 1540 × 240 × 275 |
